MICHELIN XSM D2+ PRO
/1
  • Robustness
  • Underground Mining

MICHELIN XSM D2+ PRO

Extreme conditions demand tough tyres

  • Increased load capacity
  • Improved aggression resistance
  • Improved tyre life
Loading… dimensions for this product
Find a dealer Technical information
Close
MICHELIN
XSM D2+ PRO
Select a dimension
back
Select a dimension
  • 17.5R25 L5*** TL
  • 18.00R25 L5*** TL
  • 26.5R25 L5S*** TL
  • 29.5R29 L5S*** TL
Close
MICHELIN
XSM D2+ PRO
Select a dimension
back
Select a dimension
  • 17.5R25 L5*** TL
  • 18.00R25 L5*** TL
  • 26.5R25 L5S*** TL
  • 29.5R29 L5S*** TL

Increased Load Capacity

Up to 18% more load capacity. (1)

Improved Aggression Resistance (2)

Due to new cables and NRF technology (reinforced sidewall plies).

Improved Tyre Life

Tyre life improved (3) in the harshest of conditions thanks to optimised tread compounds (3).

Picto pro line header Tyre

NRF technology


Two extra plies added to the tyre structure contain cross-woven nylon cords built into the rubber for greater resistance and robustness.

MICHELIN® Pro Line of Underground Tires – NRF Technology
  • Technical Specifications
  • Load & Pressure

Technical Specifications

Product MICHELIN XSM D2+ PRO - 17.5R25
Overall Diameter 1396 mm / 55 inch
Section width 453 mm / 18 inch
Recommended rims 14.00/1.5
Rolling circumference (mm) 4246
Filling volume 100% (lts) 272 l / 72 gal
Tread depth 78 mm / 3.1 inch
Loaded radius 641 mm
TRA code L-5
CAI 822869

Load & Pressure

Take into account the load and the type of work to be done to adjust the pressures

bar

psi

3

44

3.5

51

4

58

4.5

65

5

73

5.5

80

6

87

6.5

94

7

102
(kg - lbs) loader

front-laden

4750

10472

5450

12015

6000

13228

6500

14330

7100

15653

7500

16535

8000

17637

8500

18739

10000

22046

rear-unladen

3800

8378

4360

9612

4800

10582

5200

11464

5680

12522

6000

13228

6400

14110

6800

14991

8000

17637
